Dual Master Controllers
Dual Master Controllers are used for remote operation of Contactors
in equipment such as E.O.T. Cranes & Rolling mills drives. The
Controllers are made in dust proof enclosure in IP-41 degree of
protection, up to 6 notches either side with maximum 24 contacts as
per desired sequence.
Spring return arrangement & Dead man's handle arrangement are
also available.
Dual Master Controller with one universal handle allows a crane
operator to control both Bridge & Trolley motions with one handle,
Simultaneous operation of Bridge & Trolley motions provide for
greater spotting accuracy and faster movement of loads. The handle
of joystick can be moved into any quadrant and any position.
Universal controllers are also used for hoist/grab motion. Master
Controller are coupled with universal joint for operation of controller
individually / jointly to get desired motion operation
